Pulling force : 3630 kg
Motor : 12V DC Wound Series
Cable : 29m x 8mm
Brake : automatic
Includes remote control with 3.7m cable
Gear construction : 3 planetary gears
Recommended battery : 650 minimum CCA for trolling
Transmission ratio : 216:1
Weight : 34.27 kg
Drum diameter / Length : 64mm / 230mm
New from WARN - instead of the classic 4 relay control box, now equipped with waterproof contactor control box for protection against dust and water, meaning only one industrial relay for long life
Attention. The winches are mounted on a dedicated bracket, specially made for each vehicle model! This is not included and must be ordered separately!
The minimum tractive force for a winch is calculated by multiplying 1.5 by the maximum authorized mass of the vehicle in question!
CAUTION - when mounting winches on cars, there may be cases where it is necessary to relocate the control box for easier remote control access, a process which may incur additional costs during installation - using extension / relocation kits for control boxes.
